Product Description

TSD-850 Auto blade bending machine

Machine Model No.:  TSD-850
Auto blade bendi ng machine
Automatic blade bending machine (TSD-850)  is numerical control program, it’s developed and designed for the convenience of the user, it’s easy to operate and support DXF file of auto CAD, support file(DXF,AI,NC.)

Bending Blade thickness:  0.71mm/1.07mm/1.42mm 2PT/3PT/4PT
Bending Blade height:  23.8-50mm-60mm
--------------------------------------------------------------------------------------------------------------------------------------
Features:
Processing of functions such as fully automatic bending, bridge, cutting.
1. Panasonic Servo motor system + Ball-screw guide rail design, avoiding skidding and error in length.
2. Unique imported mould tool design, easy to bend pattern, high precision of size, durable.
3. In order guarantee precision and long-life span, transmission and control parts are imported.
4. Self-developed latest bending control system, easy to operate and upgrade available.
5. Fully English & Chinese interface, easy to learn how to operate, make bending work easy.
6. It can be installed soon after bending patterns form the machine, no need extra more hard work.
7. Exactly to realize fully automatic bending, help to save plate making time.
Technical Parameter:

Blade thickness(mm)
0.71mm/1.05mm/1.42mm

Blade height(mm)
23.8-60mm

Max. bending angle
100°

Min. ARC radius of 90 degree
0.4mm

Front Min. bending size
2.5mm

Back Min. cutting size
1.0mm

Feeding precision
±0.03mm

Bending flatness
±0.2mm

Functions
Bending, cutting, lipping, bridge

Cutting methods
Swing cutting or Auto flat cutting

Optimal pattern format
dxf format

Air supply
0.6mpa

Power supply
380∨ 50/60HZ(Standard)

Machine total power
1.3kw

Gross weight.
450KG

Overall dimension
2700×1050×1350mm(L×W×H)

=============================================================================
After-sales service:
1. English-speaking engineer is available for end-user's machine installation and training under buy’s cost around 5days.
2. English software, installation and related training instructions and videos are available for end-users.
3. In case of any problems or questions about laser technology you can always refer to  TSD Laser .
4. With our customer-orientated service support, maintenance and repair costs will be kept low.
5. One year guarantee for machine is promised.

For installation: TSD offer operation instructions and videos
Web： www.sztsdlaser.com


Payment Terms︰ TT
